CT 7.5 LCRS
The entry-level speaker in the CT700 range delivers outstanding spaciousness, imaging and definition through its single 7" Kevlar® bass/midrange unit.
The entry-level speaker in the CT700 range delivers
outstanding spaciousness, imaging and definition through its single 7" Kevlar®
bass/midrange unit.
Designed to slot discreetly into custom-built cabinetry, every speaker in the
CT700 range can take on either front, centre or surround duties within a
multi-channel theatre set-up. Each speaker used Kevlar drive units, and features
B&W’s famous Nautilus tube-loaded tweeters – a pioneering technology that
draws away and dampens distorting sound waves from the rear of the drive units,
thereby producing a much purer sound from the front.
|
Technical features |
Nautilus™ tube loaded tweeter |
|
Description |
2-way vented-box system |
|
Drive units |
1x ø25mm (1 in) cloth dome high-frequency |
|
Frequency range |
-6dB at 48Hz and 28kHz |
|
Frequency response |
55Hz – 22kHz ±3dB on reference axis |
|
Dispersion |
Within 2dB of reference response |
|
Sensitivity |
92dB spl (2.83V, 1m) |
|
Harmonic distortion |
2nd and 3rd harmonics (90dB, 1m) |
|
Nominal impedance |
8 ohm (minimum 4.6 ohm) |
|
Crossover frequency |
4kHz |
|
Recommended amplifier power |
50W – 120W into 8 ohm on unclipped programme |
|
Max. recommended cable impedance |
0.1ohm |
|
Dimensions |
Height: 305mm (12 in) |
|
Net weight |
11.5kg (25.4lb) |
|
Finishes |
Cabinet Black painted |
