HTM 62 S2
Ideal at the centre of most home theatre systems, the HTM62
S2 is the smaller centre speaker that still excels at delivering power and
precision..jpg)
Like its bigger sibling the HTM61 S2, the HTM62 S2 now
features an improved Decoupled Double dome tweeter design, ideal for delivering
the clarity needed for dialogue. The double dome delivers a more precise
response, while decoupling the tweeter from the main enclosure removes unwanted
resonances and vibration. The result is absolutely clear.
The HTM62 S2 also features two 5-inch drivers that use Kevlar cones, for an
ideal mix of punch and precision. The result, combined with the Decoupled
Double Dome tweeter, is a centre speaker that sounds simply stunning.
The clarity and power of the HTM62 doesn't command a space premium either.
Smaller than the HTM61, it's absolutely at home in just about any setup. And
like the HTM62, it can be used horizontally or vertically, depending on space.
|
Woven Kevlar |
|
|
Crossover Tuning |
|
|
Nautilus Tapering Tube |
|
|
Flowport |
|
|
Technical features |
Decoupled Double Dome aluminium tweeter with Nautilus™
tube loading |
|
Description |
2-way vented-box system |
|
Drive units |
1x ø25mm (1 in) aluminium dome high-frequency |
|
Frequency range |
-6dB at 48Hz and 50kHz |
|
Frequency response |
70Hz - 22kHz ±3dB on reference axis |
|
Dispersion |
Within 2dB of reference response |
|
Sensitivity |
87dB spl (2.83V, 1m) |
|
Harmonic distortion |
2nd and 3rd harmonics (90dB, 1m) |
|
Nominal impedance |
8Ω (minimum 3.5Ω) |
|
Crossover frequencies |
4kHz |
|
Recommended amplifier power |
25W - 120W into 8Ω on unclipped programme |
|
Max. recommended cable impedance |
0.1Ω |
|
Dimensions |
Height: 160mm (6.3 in) |
|
Net weight |
7.9kg (17.3 lb) |
|
Finishes |
Black Ash |
