HTM 61 S2
The perfect partner for the 683 S2 in a commanding home theatre system, this true three-way centre speaker features two 6.5-inch drivers, an FST midrange and a Decoupled Double Dome tweeter.
The HTM61 S2 now features a Decoupled Double Dome tweeter,
ideal for delivering the clarity needed for dialogue. The double dome enhances
rigidity without adding weight, for a more precise response, while decoupling
the tweeter from the main enclosure removes unwanted resonances and vibration.
The result is absolutely clear..jpg)
Using construction techniques found in the 600 Series floorstanders, the HTM61
S2 also features two 6.5-inch bass drivers that use new aluminium cones, for an
ideal mix of punch and precision.
Below the Decoupled Double Dome tweeter and between the two 6.5-inch bass
drivers lies an FST midrange driver. And to the rear of the speaker are two
Flowports. Together these ensure stunning audio clarity is carried across the
entire frequency range, and a new symmetrical design improves integration and
sound dispersion. The result is a serious centre speaker - stunning for
big-screen action.
|
Woven Kevlar |
|
|
Crossover Tuning |
|
|
Nautilus Tapering Tube |
|
|
Flowport |
|
|
Mushrooms |
|
|
FST |
|
|
Technical features |
Decoupled Double Dome aluminium tweeter with Nautilus™
tube loading |
|
Description |
3-way vented-box system |
|
Drive units |
1x ø25mm (1 in) aluminium dome high-frequency |
|
Frequency range |
-6dB at 42Hz and 50kHz |
|
Frequency response |
50Hz - 22 kHz ±3dB on reference axis |
|
Dispersion |
Within 2dB of reference response |
|
Sensitivity |
88dB spl (2.83V, 1m) |
|
Harmonic distortion |
2nd and 3rd harmonics (90dB, 1m) |
|
Nominal impedance |
8Ω (minimum 5.2Ω) |
|
Crossover frequencies |
400Hz, 4kHz |
|
Recommended amplifier power |
30W - 150W into 8Ω on unclipped programme |
|
Max. recommended cable impedance |
0.1Ω |
|
Dimensions |
Height: 218mm (8.6 in) |
|
Net weight |
17.2kg (37.8 lb) |
|
Finishes |
Black Ash |
