GRAPHIC

GRAPHIC

2-way, bassreflex wall mounted speaker

3 exchangeable magnetic cloth covers: black, light brown, lime green

Black glass front improves acoustics

Design

Graphic is the result of close cooperation between Jamo engineers and acclaimed designers Wojtek & Hånsbek. This wall-mounted stereo speaker is a discreet audio solution for living or dining rooms.

Graphic includes three exchangeable cloth covers in black, light brown and lime green. The front covers are mounted on magnetic frames, so that they can be exchanged by the season, your mood or by interior design-without using tools.

The combination of the flat beveled cabinet and black glass front makes these speakers works of art-and of brilliant sound-that beautifully decorate any wall

Technology

Graphic is a 2-way bassreflex speaker. Placed on the wall, it provides powerful bass reproduction because the angled, rear-firing bass reflex port uses the wall as an acoustic amplifier to increase response. This means that the speakers, despite their compact size-just 3.1 inches thick-are capable of outperforming larger speakers.

Graphic has far more to offer than great looks. It includes a 5.25-inch woofer/midrange unit and a 1-inch tweeter. The black glass front isn't just a stylish solution; because glass is resonance-deadening, the front plate is very rigid, improving acoustic properties.

System Type 2-way bassreflex

Impedance 8

Weight (Kg/lb) 6.9 / 15.2

Tweeter (mm/in) 25 / 1

Woofer (mm/in) 133 / 5¼

Product dimensions (mm/in, HxWxD) 440 x 390 x 80 / 17.3 x 15.4 x 3.1

Product Finish Black glass (black, light brown and lime green grilles included)

Frequency Response (Hz, +/-3dB) 45 - 20,000

Power Handling (Watts Long/Short Term) 60 / 90

Sensitivity (dB, 2.8V/1m) 88
